Individual hose record
730503002091 Hose Repair Specifications
Excavator · Sunward · SWE225E-3H · Attachments – Breaker
Finished length520 mm
Locate this hose
Installation diagram — Pipe No. 5
Locate Pipe No. 5 in the diagram, then confirm part number 730503002091 before removing the hose.
Repair specifications
- Part number
- 730503002091
- Diagram pipe number
- 5
- Installation route
- Hydraulic tank → connector plate (under boom)Original Chinese: 液压油箱~接线板(大臂下)
- Hose specification
- DN25;6SH-16;35MPa
- Finished length
- 520 mm
- Working pressure
- 35 MPa
- Left fitting
- 45°公制内螺纹24°锥带O形圈-重型
- Right fitting
- 90°公制内螺纹24°锥带O形圈-重型
- Quantity
- 1
