- Length
- 1,780 mm
- Specification
- DN32;6SH-20;42MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- Light-series flangeOriginal Chinese: 法兰-轻型
Individual hose record
4439932 Hose Repair Specifications
Excavator · Hitachi · ZX350F · Boom Assembly
Finished length1,780 mm
Locate this hose
Installation diagram — Pipe No. 12A
Locate Pipe No. 12A in the diagram, then confirm part number 4439932 before removing the hose.
Repair specifications
- Part number
- 4439932
- Diagram pipe number
- 12A
- Installation route
- 大臂左2
- Hose specification
- DN32;6SH-20;42MPa
- Finished length
- 1,780 mm
- Working pressure
- 42 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- Light-series flangeOriginal Chinese: 法兰-轻型
- Quantity
- 1
