Individual hose record
4698008 Hose Repair Specifications
Excavator · Hitachi · ZX120-3 · Hydraulic Tank
Finished length2,900 mm
Locate this hose
Installation diagram — Pipe No. 3B
Locate Pipe No. 3B in the diagram, then confirm part number 4698008 before removing the hose.
Repair specifications
- Part number
- 4698008
- Diagram pipe number
- 3B
- Installation route
- 液压油箱~进回油阀
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 2,900 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
