Individual hose record
4721465 Hose Repair Specifications
Excavator · Hitachi · ZX130-5G · Control Valve
Finished length1,000 mm
Locate this hose
Installation diagram — Pipe No. 1
Locate Pipe No. 1 in the diagram, then confirm part number 4721465 before removing the hose.
Repair specifications
- Part number
- 4721465
- Diagram pipe number
- 1
- Installation route
- 分配阀上~回转马达
- Hose specification
- DN19;1SN-12;7Mpa
- Finished length
- 1,000 mm
- Working pressure
- 7 MPa
- Left fitting
- 45°美制内螺纹平面密封
- Right fitting
- 90° elbow, American female thread, flat-face sealOriginal Chinese: 90°美制内螺纹平面密封
- Quantity
- 1
