Individual hose record
4306086 Hose Repair Specifications
Excavator · Hitachi · ZX600LC · Grease Lines
Finished length1,600 mm
Locate this hose
Installation diagram — Pipe No. 14
Locate Pipe No. 14 in the diagram, then confirm part number 4306086 before removing the hose.
Repair specifications
- Part number
- 4306086
- Diagram pipe number
- 14
- Installation route
- 小臂黄油管
- Hose specification
- DN10;2SN-6;27.5MPa
- Finished length
- 1,600 mm
- Working pressure
- 27.5 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
