Individual hose record
4654943 Hose Repair Specifications
Excavator · Hitachi · ZX450LC-3 · Grease Lines
Finished length1,300 mm
Locate this hose
Installation diagram — Pipe No. 13A
Locate Pipe No. 13A in the diagram, then confirm part number 4654943 before removing the hose.
Repair specifications
- Part number
- 4654943
- Diagram pipe number
- 13A
- Installation route
- 黄油分配阀~过渡阀块(大臂下)
- Hose specification
- DN6;1SN-4;10.5MPa
- Finished length
- 1,300 mm
- Working pressure
- 10.5 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 公制卡套式
- Quantity
- 1
