Individual hose record
4466326 Hose Repair Specifications
Excavator · Hitachi · ZX80 · Swivel Joint
Finished length800 mm
Locate this hose
Installation diagram — Pipe No. 18
Locate Pipe No. 18 in the diagram, then confirm part number 4466326 before removing the hose.
Repair specifications
- Part number
- 4466326
- Diagram pipe number
- 18
- Installation route
- 回转接头~分配阀前左
- Hose specification
- DN12;4SP-08;41.5MPa
- Finished length
- 800 mm
- Working pressure
- 41.5 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
