Individual hose record
4682879 Hose Repair Specifications
Excavator · Hitachi · ZX190W-3 · Attachments
Finished length3,450 mm
Locate this hose
Installation diagram — Pipe No. 23A
Locate Pipe No. 23A in the diagram, then confirm part number 4682879 before removing the hose.
Repair specifications
- Part number
- 4682879
- Diagram pipe number
- 23A
- Installation route
- 中转接头~电磁阀(隔板)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 3,450 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
