Individual hose record
4671446 Hose Repair Specifications
Excavator · Hitachi · ZX135US-3 · Attachments
Finished length1,850 mm
Locate this hose
Installation diagram — Pipe No. 4A
Locate Pipe No. 4A in the diagram, then confirm part number 4671446 before removing the hose.
Repair specifications
- Part number
- 4671446
- Diagram pipe number
- 4A
- Installation route
- 过渡阀块(流速切换)~过渡阀块(推土铲手柄)
- Hose specification
- DN10;1SN-6;18MPa
- Finished length
- 1,850 mm
- Working pressure
- 18 MPa
- Left fitting
- 美制内螺纹74°内锥双六角
- Right fitting
- 90°美制内螺纹74°内锥
- Quantity
- 1
