Individual hose record
4445276 Hose Repair Specifications
Excavator · Hitachi · ZX190W-3 · Attachments – Breaker
Finished length400 mm
Locate this hose
Installation diagram — Pipe No. 10
Locate Pipe No. 10 in the diagram, then confirm part number 4445276 before removing the hose.
Repair specifications
- Part number
- 4445276
- Diagram pipe number
- 10
- Installation route
- 电磁阀(破碎器)~电磁阀(破碎器)
- Hose specification
- DN10;1SN-06;18MPa
- Finished length
- 400 mm
- Working pressure
- 18 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 2
