Diagram Pipe No. 25A
4420423
Installation route: Swivel joint → travel motorOriginal Chinese: 回转接头~行走马达
- Length
- 500 mm
- Specification
- DN12;1SN-8;7Mpa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
Individual hose record
4674457 Hose Repair Specifications
Excavator · Hitachi · ZX190W-3 · Swivel Joint
Finished length1,500 mm
Locate this hose
Installation diagram — Pipe No. 29A
Locate Pipe No. 29A in the diagram, then confirm part number 4674457 before removing the hose.
Repair specifications
- Part number
- 4674457
- Diagram pipe number
- 29A
- Installation route
- 回转接头~电磁阀
- Hose specification
- DN6;1SN-4;7Mpa
- Finished length
- 1,500 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
- Quantity
- 1
