Individual hose record
9234556 Hose Repair Specifications
Excavator · Hitachi · ZX210W · Attachments – Lock Valve
Finished length2,500 mm
Locate this hose
Installation diagram — Pipe No. 23
Locate Pipe No. 23 in the diagram, then confirm part number 9234556 before removing the hose.
Repair specifications
- Part number
- 9234556
- Diagram pipe number
- 23
- Installation route
- 分配阀上左~过渡阀块(锁止阀)
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 2,500 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
