Individual hose record
4701871 Hose Repair Specifications
Excavator · Hitachi · ZX135US-6N · Control Lever
Finished length1,300 mm
Locate this hose
Installation diagram — Pipe No. 19
Locate Pipe No. 19 in the diagram, then confirm part number 4701871 before removing the hose.
Repair specifications
- Part number
- 4701871
- Diagram pipe number
- 19
- Installation route
- 中转接头~
- Hose specification
- DN10;1SN-6;18MPa
- Finished length
- 1,300 mm
- Working pressure
- 18 MPa
- Left fitting
- 美制内螺纹74°内锥双六角
- Right fitting
- 美制内螺纹74°内锥双六角
- Quantity
- 1
