Individual hose record
4442766 Hose Repair Specifications
Excavator · Hitachi · ZX120 · Hydraulic Pump
Finished length2,000 mm
Locate this hose
Installation diagram — Pipe No. 17A
Locate Pipe No. 17A in the diagram, then confirm part number 4442766 before removing the hose.
Repair specifications
- Part number
- 4442766
- Diagram pipe number
- 17A
- Installation route
- 液压泵~中转接头
- Hose specification
- DN10;1SN-6;7Mpa
- Finished length
- 2,000 mm
- Working pressure
- 7 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 45°美制内螺纹37°内锥
- Quantity
- 1
