Individual hose record
4343392 Hose Repair Specifications
Excavator · Hitachi · EX550LC · Hydraulic Tank
Finished length1,500 mm
Locate this hose
Installation diagram — Pipe No. 12
Locate Pipe No. 12 in the diagram, then confirm part number 4343392 before removing the hose.
Repair specifications
- Part number
- 4343392
- Diagram pipe number
- 12
- Installation route
- 液压油箱~电磁阀(分配阀)
- Hose specification
- DN6;2层纤维-4;14MPa
- Finished length
- 1,500 mm
- Working pressure
- 14 MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Quantity
- 1
Same system
Related Hoses
- Length
- 450 mm
- Specification
- DN6;2层纤维-4;14MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 90°美制内螺纹37°内锥
- Length
- 2,200 mm
- Specification
- DN10;1层纤维-6;14MPa
- Left fitting
- 美制内螺纹37°内锥
- Right fitting
- 美制内螺纹37°内锥
