Individual hose record
4429016 Hose Repair Specifications
Excavator · Hitachi · ZX120-3 · Grease Lines
Finished length2,250 mm
Locate this hose
Installation diagram — Pipe No. 6
Locate Pipe No. 6 in the diagram, then confirm part number 4429016 before removing the hose.
Repair specifications
- Part number
- 4429016
- Diagram pipe number
- 6
- Installation route
- Left boom-cylinder grease lineOriginal Chinese: 左大臂油缸黄油管
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 2,250 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 1
Same system
Related Hoses
Diagram Pipe No. 7
4429018
Installation route: Right boom-cylinder grease lineOriginal Chinese: 右大臂油缸黄油管
- Length
- 2,150 mm
- Specification
- DN6;1SN-04;22.5MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
