Individual hose record
4696161 Hose Repair Specifications
Excavator · Hitachi · ZX135US-3 · Control Valve
Finished length1,930 mm
Locate this hose
Installation diagram — Pipe No. 19A
Locate Pipe No. 19A in the diagram, then confirm part number 4696161 before removing the hose.
Repair specifications
- Part number
- 4696161
- Diagram pipe number
- 19A
- Installation route
- 分配阀后左~接线板(大臂)
- Hose specification
- DN12;4SP-8;34.5Mpa
- Finished length
- 1,930 mm
- Working pressure
- 34.5 MPa
- Left fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Right fitting
- American female thread, flat-face sealOriginal Chinese: 美制内螺纹平面密封
- Quantity
- 1
