Individual hose record
730502009588 Hose Repair Specifications
Excavator · Sunward · SWE25UF · Control Valve
Finished length420 mm
Locate this hose
Installation diagram — Pipe No. 13
Locate Pipe No. 13 in the diagram, then confirm part number 730502009588 before removing the hose.
Repair specifications
- Part number
- 730502009588
- Diagram pipe number
- 13
- Installation route
- 分配阀B9~回转马达
- Hose specification
- DN10;2SN-06;27.5MPa
- Finished length
- 420 mm
- Working pressure
- 27.5 MPa
- Left fitting
- 公制内螺纹24°锥带O形圈-轻型
- Right fitting
- 90°公制内螺纹24°锥带O形圈-轻型
- Quantity
- 1
