Individual hose record
4316009 Hose Repair Specifications
Excavator · Hitachi · ZX650LC-3 · Grease Lines
Finished length3,650 mm
Locate this hose
Installation diagram — Pipe No. 2
Locate Pipe No. 2 in the diagram, then confirm part number 4316009 before removing the hose.
Repair specifications
- Part number
- 4316009
- Diagram pipe number
- 2
- Installation route
- 大臂油缸黄油管
- Hose specification
- DN6;1SN-04;22.5MPa
- Finished length
- 3,650 mm
- Working pressure
- 22.5 MPa
- Left fitting
- 美制内螺纹74°内锥
- Right fitting
- 美制内螺纹74°内锥
- Quantity
- 2
